Page #30 background imageLoading...
Page #30 background image
30 SG-150-1
Name
Possible
values
Default
Description
Modbus
type & addr
AlarmStatus.Alarm8
unit None
scale 1
uint16
-
IR 11208
AlarmStatus.Alarm9
unit None
scale 1
uint16
-
IR 11209
AlarmStatus.Alarm10
unit None
scale 1
uint16
-
IR 11210
The registers AlarmStatus.Alarm 1 .. Alarm10 are 16 bit values. The bit decoding is as follows:
Bit
Description
0 .. 9
Index number (not display code)
Please refer to cross reference table below
10..12
Alarm severity:
0: None,
1: Log,
2: Info,
3: Warning,
4: Critical,
5: Fault
13..13
(reserved)
14..15
Alarm state:
0: Clear,
1: Inactive,
2: Active,
3: Set (condition is present)
Cross reference table between alarm number and internal alarm index.
Alarm
number
Index
number
Description
0
0
No Fault
1000
119
Too many identical timed resets in 24 hours
1001
120
Too many timed resets in 1 hour
1100
1
Serial Control Timeout
1200
2
Mains Failure
2000
72
LOCKED
2700
73
Setup Fault
3001
3
Envelope: SST Low, SDT Low
3002
4
Envelope: SST Low
3003
5
Envelope: SST Low, SDT High
3004
6
Envelope: SDT High
3005
7
Envelope: SST High, SDT High
3006
8
Envelope: SST High
3007
9
Envelope: SST High, SDT Low
3008
10
Envelope: SDT Low
3010
11
Envelope: Startup Timeout
3011
12
Envelope: Configuration Failure
3022
74
Too Many Compressor Starts
3024
98
Minimum Compressor Stop Time Not Respected
