Bitzer CM-SW-01 User Manual

SG-150-1 31
Alarm
number
Index
number
Description
3025
99
Minimum Compressor Run Time Not Respected
3026
100
Minimum Compressor Start To Start Time Not Respected
3027
71
Compressor Start without being fully unloaded
3302
78
Discharge Temperature High
3400
68
Suction Pressure Low
3411
69
Discharge Pressure High
3431
90
High Pressure Switch
3500
15
Oil Level Low
3501
133
Oil Flow
3502
134
Oil Pressure Low
3503
137
Oil Stop Valve
3520
102
Oil Injection Has No Effect
3900
16
Locked Rotor
4201
18
Motor Phase Loss
4202
19
Motor Phase Sequence
4220
135
Motor Frequency Low
4221
136
Motor Frequency High
4301
20
Motor Temperature High
4302
84
Motor Temperature Cooldown
5851
39
HW: 24V
6700
49
Config Data: No File
6701
50
Config Data: CRC Error
6702
51
Config Data: Wrong Version
6703
52
Config Data: Read Only
6810
54
HW: 3.3V
6811
55
HW: User 5V
6813
70
HW: 24V
6900
91
Datalog error
7304
62
Sensor: Motor Thermistor
7308
85
Sensor: Discharge Temperature
7320
86
Sensor: Aux Temperature
7401
87
Sensor: Suction Pressure
7402
88
Sensor: Discharge Pressure
7403
94
Sensor: Suction Pressure Signal Low
7404
95
Sensor: Suction Pressure Signal High
7405
96
Sensor: Discharge Pressure Signal Low
7406
97
Sensor: Discharge Pressure Signal High
7510
89
Sensor: Oil protection
7511
80
Sensor: Oil protection 2
7580
121
Slider: No Sensor Detected
7581
122
Slider: Less Than Two Magnets Detected
7582
123
Slider: Sample Data Invalid
7583
124
Slider: More Than Two Magnets Detected
7584
125
Slider: Position Invalid
8200
92
Output Current: Total Value Low
8201
93
Output Current: Total Value High
8202
103
Output Current: Oil Heater Low
