BIXOLON BCD-3000 User Manual

Ver. 1.01
- 10 -
BCD-2000/3000
5. Windows Driver Specification
5-1 Windows Driver function
• The windows driver which is provided for BCD-2000/3000 has the following functions.
1) 30 characters x 4 lines or 20 characters x 2 lines (BCD-2000)
* Use BCD Utility for changing the default configuration of BCD-2000.
2) 20 characters x 2 lines (BCD-3000)
3) NV Logo display / Text display using a device font.
5-2 Device fonts for text display
5-2-1 Device fonts for text display
• The Windows Driver of BCD-2000/3000 supports the fonts listed below. The device font
names below indicate in which line the font is used. The font name with ʺ2ndʺ is the
font
used in the second line on the display.
Font Name
Font Size
BCD 1st Line
7 point
BCD 2nd Line
BCD 3rd Line
BCD 4th Line
1) BCD 1st Line
- Characters are displayed in 1st line.
2) BCD 2nd Line
- Characters are displayed in 2nd line.
3) BCD 3rd Line
- Characters are displayed in 3rd line.
* 3
rd
line and 4
th
line are not available for BCD-3000.
* BCD-2000 also is not available depending on the memory switch configuration.
4) BCD 4th Line
- Characters are displayed in 4th line.
* 3
rd
line and 4
th
line are not available for BCD-3000.
* BCD-2000 also is not available depending on the memory switch configuration.
