BIXOLON SRP-275II Service Manual

Rev. 1.00
- 90 -
SRP-275II
6-3 Lubricants and adhesive application
Lubrication and application adhesive plays an important role in maintaining this printer at its initial
performance level, throughout a long product life as well as preventing potential troubles. Make sure to apply
the specified lubricants or adhesive in the appropriate amounts at the specified intervals .
6-3-1 Lubricant requirements
Before applying the lubricants during an assembly or disassembly procedure, be sure to first thoroughly
clean the part to be lubricated. For details on lubrication see "4.2.3 Lubrication points" and "4.2.2 Lubricant
types".
• Lubrication Classes
Concerning the lubrication interval, lubrication should be performed periodically according to the lubrication
classes described below. If lubrication becomes deficient due to cleaning, disassembly or parts
replacement, be sure to lubricate the required part regardless of the lubrication interval.
- A : Lubrication every 6 months.
- B : Lubrication after on overhaul or every 1 million lines
6-3-2 Lubricant types
The type of oil used greatly influences performance and durability, and special attention is required to its low
temperature characteristic. Consequently, the oils to be used with this printer are specified by us on the
basis of the result of the thorough analyses of technical data for many types of oils and various experiments.
2 types of oils to be used with this printer are:HG-31S, G 948P
6-3-3 Lubrication points
No Lubrication point Oil type
1
2
3
4
5
6
7
Outer periphery of shaft hold roller
Contact point between cam of head carriage and ribbon frame
Contact point between shaft ribbon frame and lever color change
Contact point between spring ribbon feeder and ribbon feeder
Outer periphery of shaft head carriage
Outer periphery of all gears
Outer periphery of shaft head guide
HG-31S
HG-31S
HG-31S
HG-31S
G948P
HG-31S
HG-31S
• Precautions on lubrication
Never apply lubricant to Gear Ratchet or outer periphery of Rubber Roller. If lubricant has accidentally been
applied to these parts, clean them with alcohol.
6-3-4 Adhesive application requirements
To prevent from screws getting loose by various vibration while transporting the printer, adhesive should be
applied after tightening screws.
6-3-5 Adhesive types
The adhesive type for use with this printer : Screwlock

BIXOLON SRP-275II Specifications

General

Type	POS printer
Print speed	5.1 lps
Maximum resolution	80 x 144 DPI
Maximum roll diameter	85 mm
Supported paper width	76.5 mm
Maximum printing width	63.5 mm
Flash memory	2 MB
RAM capacity	0.008 GB
Autocutter durability	1.5 million cuts
Built-in sensors details	Paper End, Paper Near End, Wall Mounting Paper Near End, Rear Cover Open, Black Mark
AC input voltage	100-240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Mean cycles between failures (MCBF)	18000000
Product color	Black
USB port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Parallel ports quantity	1
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	239 mm
Width	160 mm
Height	157 mm
Weight	2400 g
