BIXOLON SRP-330III User Manual

Ver. 1.00
- 10 -
SRP-330III/332III
Product Introduction
SRP-330III/332III printers have been designed to be connected to various types of
electronic devices such as POS (Point Of Sales), and computer peripheral devices.
The main features of the printer are as follows
1. Maximum 250mm/s printing speed
2. Thermal transfer method printing
3. Interface
- USB & Serial (SRP-33xIIIS)
- USB & Paralell (SRP-33xIIIP)
- USB & Ethernet & Serial (SRP-33xIIIES)
4. Equipped with data buffer (receives print data even while printing)
5. Peripheral driver circuits control external devices such as cash registers
6. Can print a range of barcodes
7. Range of printing density selectable
(controlled with virtual memory switch management)

BIXOLON SRP-330III Specifications

General

USB connector	USB Type-B
Serial interface	Yes
Serial interface type	RS-232
USB 2.0 ports quantity	1
Connectivity technology	Wired
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50/60 Hz
Wi-Fi	No
Maximum printing width	72 mm
Printing media thickness	0.05 - 0.08 µm
Roll core diameter (max)	80 mm
Cables included	USB
Type	POS printer
Print technology	Direct thermal
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Flash memory	64 MB
Storage media	Flash
Internal memory	128 MB
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, ITF, PDF417, QR Code, UPC-A, UPC-E
Built-in sensors details	Paper End, Cover Open
Product color	Black

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	146 mm
Weight	1600 g
