BIXOLON SRP-330III User Manual

Ver. 1.00
- 9 -
SRP-330III/332III
Manual Introduction
This manual provides basic information on printers and provides ways to install, use, and
check them. In order to protect the safety of users and prevent property damage, be fully
familiar with this manual before using the product. Please use it.
Manual Symbol Introduction
Precaution
& Warning
It describes death, physical injuries, serious financial losses,
and damage to data etc. that can be caused to the user.
Note
It provides additional information on the function and
performance of the product.

BIXOLON SRP-330III Specifications

General

USB connector	USB Type-B
Serial interface	Yes
Serial interface type	RS-232
USB 2.0 ports quantity	1
Connectivity technology	Wired
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50/60 Hz
Wi-Fi	No
Maximum printing width	72 mm
Printing media thickness	0.05 - 0.08 µm
Roll core diameter (max)	80 mm
Cables included	USB
Type	POS printer
Print technology	Direct thermal
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Flash memory	64 MB
Storage media	Flash
Internal memory	128 MB
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, ITF, PDF417, QR Code, UPC-A, UPC-E
Built-in sensors details	Paper End, Cover Open
Product color	Black

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	146 mm
Weight	1600 g
