◈ Specifications
Item Details
Printer
Printing Method Thermal Line Printing
Dot Density
SRP-350plusII: 180 dpi (7dots/mm)
SRP-352plusII: 203 dpi (8dots/mm)
Printing Width
3 inches 72 mm
2 inches 48 mm
Characters per line
(Default)
SRP-350plusII: 42 (Font A) / 56 (Font B) /
56 (Font C)
SRP-352plusII: 48 (Font A) / 64 (Font B) /
64 (Font C)
Printing Speed *1)
SRP-350plusII: 59.10 lines/sec, 250 mm/sec
SRP-352plusII: 61.33 lines/sec, 230 mm/sec
Receive Buffer Size 4K Bytes
SMPS Input Voltage 100~240 VAC
Frequency 50/60 Hz
SMPS Output Voltage 24 VDC
Temperature
0 ~ 40 ℃ (Operating)
-20 ~ 60 ℃ (Storage)
Humidity
10 ~ 80 % RH (Operating)
10 ~ 90 % RH (Storage)
; Except for paper
Auto Cutter 1,800,000 Cuts
Mechanism MCBF *2) 70,000,000 Lines
Paper
Paper Type Paper Roll
Roll Width
3 inches 79.5±0.5 mm
2 inches 57.5±0.5 mm
Roll Diameter Max 83mm
Paper Thickness 0.062~0.075 mm
Paper Tube
Inner: Ø12mm (0.47”)
Outer: Ø18mm (0.71”)
※ Note
*1) Printing speed may be slower depending on the data transmission speed and the
combination of control commands.
*2) The above values are calculated under printing level 2 with recommended paper at
normal temperature.
The values may vary with environment temperature, printing level, etc.
◈ Automatic Windows driver installation for printers with Serial
/ Parallel / USB interface
1. Connect the printer to the computer and turn it on.
2. Select “Serial/Parallel/USB Auto Search and Configuration” in “Step 1: Port Setting
Wizard” screen.
3. Click the “Next” button; the computer starts searching printers.
* The range of the search is as follows.
- Serial: COM1~COM9
- Parallel: LPT1~LPT4
- USB: Plug&play
4. When the port search is complete, select the corresponding printer from “Search Result”
and click “Next” button.
5. Verify the selected printer.
You can use the “Test Print” button to print the test page.
6. Click the “Next” button to finish the installation of the Windows driver with the selected
port settings.
※ Note
If the automatic Windows driver installation fails with the selected interface, choose the
manual installation option in the second step to install the driver manually.
- Refer to the User’s Manual for detailed instructions. (Accompanying CD)
◈ Windows driver installation for Ethernet interface, manual
installation, and default values configuration
Refer to the User’s Manual (accompanying CD) for following installations besides automatic
installation for Serial / Parallel / USB interface.
1. Automatic installation for Ethernet interface
2. Manual installation
3. Default values configuration
◈ WEEE (Waste Electrical and Electric Equipment)
This marking shown on the product or its literature, indicates that is should not be
disposed with other household wastes at the end of its working life, To prevent
possible harm to the environment or human health from uncontrolled waste disposal,
please separate this from other types of wastes and recycle it responsibly to promote
the sustainable reuse of material resources. Household users should contact either the
retailer where they purchased this product, or their local government office, for details
of where and how they can take this item for environmentally safe recycling. Business
users should contact their supplier and check the terms and conditions of the purchase
contract. This product should not be mixed with other commercial wastes for disposal.
☎
BIXOLON Co., Ltd.
● Website http://www.bixolon.com
● Korea Headquarters
(Add) 7~8F, (Sampyeong-dong), 20, Pangyoyeok-ro241beon-gil,
Bundang-gu, Seongnam-si, Gyeonggi-do, 13494, Korea (ROK)
(Tel.) +82-31-218-5500
● U.S. Office
(Add) BIXOLON America Inc., 3171 Fujita St, Torrance, CA 90505
(Tel.) +1-858 764 4580
● Europe Office
(Add) BIXOLON Europe GmbH, Tiefenbroicher Weg 35 40472 Düsseldorf
(Tel.) +49 (0)211 68 78 54 0
