BIXOLON SRP-350plusIII Command Manual

SRP-350/352plusIII
Rev. 1.00 BIXOLON
- 4 -
2. Control Commands List in Alphanumeric Order
No.
Command
Function
No.
Command
Function
1
HT
Horizontal tab
26
ESC R
Specify an international character set
2
LF
Print and line feed
27
ESC S
Select standard mode
3
FF
Form feed (in page mode)
28
ESC T
Select print direction in page mode
4
CR
Print and carriage return
29
ESC V
Turn 90° clockwise rotation mode on/off
5
CAN
Cancel the print data in page mode
30
ESC W
Set print area in page mode
6
DLE EOT
Transmit real-time status
31
ESC \
Set relative print position
7
DLE DC4
Generate pulse at real-time
32
ESC a
Set position alignment
8
ESC SP
Set the character right space
33
ESC d
Print and feed n lines
9
ESC !
Set print mode
34
ESC i
Partial cut
10
ESC $
Set absolute print position
35
ESC m
Partial cut
11
ESC %
Select/cancel user-defined character set
36
ESC p
Generate pulse
12
ESC &
Define user-defined character set
37
ESC t
Select character code table
13
ESC *
Specify bit image mode
38
ESC v
Transmit paper sensor status
14
ESC -
Turn underline mode on/off
39
ESC {
Turn upside-down print mode on/off
15
ESC 2
Select default line spacing
40
FS p
Print NV bit image
16
ESC 3
Set line spacing
41
FS q
Define NV bit image
17
ESC =
Select peripheral device
42
GS !
Select character size
18
ESC ?
Cancel user-defined characters
43
GS $
Set absolute vertical print position in
page mode
19
ESC @
Initialize printer
44
GS ( A
Execute test print
20
ESC D
Set horizontal tab positions
45
GS ( L
GS 8 L
Select graphics data
21
ESC E
Turn emphasized mode on/off
46
GS ( k
Specify and print the symbol
22
ESC G
Turn double-strike mode on/off
47
GS *
Define downloaded bit image
23
ESC J
Print and feed paper
48
GS /
Print downloaded bit image
24
ESC L
Select page mode
49
GS :
Start/end macro definition
25
ESC M
Select character font
50
GS B
Turn white/black reverse print mode on/off

BIXOLON SRP-350plusIII Specifications

General

Type	POS printer
Character size	24 x 24 mm
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Gray
Maximum roll diameter	83 mm
Supported paper width	80/58 mm
Maximum printing width	72 mm
Printing media thickness	50 - 80 µm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
USB port	Yes
Serial interface type	RS-232
USB 2.0 ports quantity	1
Connectivity technology	Wired
Wi-Fi	No
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, ITF-14, ITF-25, Micro QR Code, QR Code, UPC-A, UPC-E
Autocutter durability	1.8 million cuts
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	146 mm
Width	145 mm
Height	204 mm
