BIXOLON SRP-350plusIII Command Manual

SRP-350/352plusIII
Rev. 1.00 BIXOLON
- 5 -
No.
Command
Function
51
GS H
Select print position of HRI characters
52
GS I
Transmit printer ID
53
GS L
Set left margin
54
GS V
Select cut mode and executes a partial cut
55
GS W
Set print area width
56
GS ^
Execute macro
57
GS a
Enable/Disable Automatic Status Back (ASB)
58
GS f
Select font for HRI characters
59
GS h
Set bar code height
60
GS k
Print bar code
61
GS r
Transmit status
62
GS v 0
Print raster bit image
63
GS w
Set bar code width
64
BS M
Select device font type
65
BS V
Select cut mode and executes a partial/full
cut
66
BS ^ P
Set power saving mode

BIXOLON SRP-350plusIII Specifications

General

Type	POS printer
Character size	24 x 24 mm
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Gray
Maximum roll diameter	83 mm
Supported paper width	80/58 mm
Maximum printing width	72 mm
Printing media thickness	50 - 80 µm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
USB port	Yes
Serial interface type	RS-232
USB 2.0 ports quantity	1
Connectivity technology	Wired
Wi-Fi	No
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, ITF-14, ITF-25, Micro QR Code, QR Code, UPC-A, UPC-E
Autocutter durability	1.8 million cuts
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	146 mm
Width	145 mm
Height	204 mm
