BIXOLON SRP-770 - Printer DIP Switch Configuration

Ethernet
V 4.00
- 33 -
[Appendix 1] Printer DIP switch set up
Printer Baud rate & DSW set up Handshaking & Parity
Baud rate
DSW 1-7 DSW 1-8
57600bps OFF ON
38400bps ON ON
19200bps OFF OFF
SRP-350
9600bps ON OFF
DTR/DSR : SW 1-3 OFF
8 data bit : SW 1-4 OFF
None parity : SW 1-5 OFF
Baud rate
DSW 1-6 DSW 1-7 DSW1-8
115200bps ON ON ON
57600bps OFF OFF ON
38400bps OFF ON ON
19200bps OFF OFF OFF
9600bps OFF ON OFF
4800bps ON OFF ON
SRP-
350plus
2400bps ON OFF OFF
DTR/DSR: SW1-2 off
8 data bit: SW1-3 off
none parity: SW1-4 off
Baud rate
DSW 2-7 DSW 2-8
19200bps ON ON
9600bps OFF OFF
4800bps ON OFF
SRP-270
2400bps OFF ON
DTR/DSR : SW 2-3 OFF
8 data bit : SW 1-4 OFF
None parity : SW 1-5 OFF
Baud rate
DSW 1-1 DSW 1-2
115200bps ON ON
38400bps OFF ON
19200bps ON OFF
SRP-370
SRP-372
9600bps OFF OFF
DTR/DSR : SW 1-3 OFF
8 data bit : MSW 9
None parity : MSW 9
[Note]
Use Memory SW to change
Baud rate
DSW 2-7 DSW 2-8
19200bps ON OFF
9600bps OFF OFF
4800bps OFF ON
SRP-275
2400bps ON ON
DTR/DSR : SW 2-3 OFF
8 data bit : SW 2-4 OFF
None parity : SW 2-5 OFF
Baud rate
DSW 2-1 DSW 2-2
115200bps ON ON
57600bps OFF ON
19200bps ON OFF
SRP-770
9600bps OFF OFF
RTS/CTS: SW2-3 ON
8 data bit
none parity
Baud rate
DSW 2-1 DSW 2-2
230400bps OFF ON
115200bps ON ON
19200bps ON OFF
SRP-770Ⅱ
9600bps OFF OFF
DTR/DSR
8 data bit
None parity
Fixed
Baud rate
DSW 2-1 DSW 2-2
230400bps OFF ON
115200bps ON ON
19200bps ON OFF
SLP-T400
9600bps OFF OFF
DTR/DSR
8 data bit
None parity
Fixed
