BIXOLON SRP-E302 - Page 100

SRP-E300/302
Ver. 1.01 BIXOLON
- 100 -
GS B
Function:
Turns white/black reverse printing mode on / off
Code:
ASCII
GS
B
n
Hex
1D
42
n
Decimal
29
66
n
Range:
0 ≤ n ≤ 255
Default:
n = 0
Description:
■ This command selects white/black reverse printing mode by setting the least significant bit of n.
• When the LSB of n is 0, white/black reverse mode is turned off.
• When the LSB of n is 1, white/black reverse mode is turned on.
Remarks:
■ This command does not affect multi-byte characters such as Kanji, Japanese and Korean.
■ The right space defined by ESC SP is affected by this command.
■ In white/black reverse mode, the underline mode is not effective.
■ This mode remains effective until ESC @, printer reset or power cycling is executed.
Differences:
None
