SRP-E300/302
Ver. 1.01 BIXOLON
- 113 -
GS k
Function:
Print bar code
Code:
①
ASCII
GS
k
m
d1...dk
NUL
Hex
1D
6B
m
d1...dk
NUL
Decimal
29
107
m
d1...dk
NUL
②
ASCII
GS
k
m
n
d1...dn
Hex
1D
6B
m
n
d1...dn
Decimal
29
107
m
n
d1...dn
Range:
① 0 ≤ m ≤ 6 ② 65 ≤ m ≤ 73
K, m, n depend on the barcode system
Default:
None
Description:
■ This command selects a bar code system and prints the bar code.
• k indicates the number of bytes of bar code data.
• n specifies the number of bytes of bar code data.
• d specifies the character code data of the bar code data to be printed.
For range ①
m
Bar Code System
Range of k
Range of d
0
UPC-A
11 ≤ k ≤ 12
48 ≤ d ≤ 57
1
UPC-E
11 ≤ k ≤ 12
48 ≤ d ≤ 57
2
JAN13(EAN)
12 ≤ k ≤ 13
48 ≤ d ≤ 57
3
JAN8(EAN)
7 ≤ k ≤ 8
48 ≤ d ≤ 57
4
CODE39
1 ≤ k
48 ≤ d ≤ 57, 65 ≤ d ≤ 90,
d=32,36,37,43,45,46,47
5
ITF
1 ≤ k (even number)
48 ≤ d ≤ 57
6
CODABAR
1 ≤ k
48 ≤ d ≤ 57, 65 ≤ d ≤ 68,
d=36,43,45,46,47,58
