BIXOLON SRP-E302 Command Manual

SRP-E300/302
Ver. 1.01 BIXOLON
- 63 -
<Function 51> GS ( L pL pH m fn (fn=3, 51)
Code:
ASCII
GS
(
L
pL
pH
m
fn
Hex
1D
28
4C
pL
pH
m
fn
Decimal
29
40
76
pL
pH
m
fn
Range:
(pL + pH x 256) = 2 (pL=2, pH=0)
m=48
fn=3, 51
Default:
None
Description:
This command transmits the setting value of the memory switch corresponding to a.
Hexadecimal
Decimal
Amount of Data
Header
37H
55
1 byte
Identifier
21H
33
1 byte
Setting value
30H – 39H
48 - 57
1 - 8 bytes
NUL
00H
0
1 byte
■ The setting value is sent from bit 8 to bit 1, consisting of 8 bytes in total.
• Off: Hexadecimal = 30H / Decimal = 48
• On: Hexadecimal = 31H / Decimal = 49
Remarks:
None
Differences:
None
