BIXOLON SRP-F310 Command Manual

SRP-F310/312
Rev. 1.01 BIXOLON
- 5 -
No.
Command
Function
51
GS B
Turn white/black reverse print mode on/off
52
GS H
Select print position of HRI characters
53
GS I
Transmit printer ID
54
GS L
Set left margin
55
GS V
Select cut mode and executes a partial cut
56
GS W
Set print area width
57
GS ^
Execute macro
58
GS a
Enable/disable Automatic Status Back (ASB)
59
GS f
Select font for HRI characters
60
GS h
Set bar code height
61
GS k
Print bar code
62
GS r
Transmit status
63
GS v 0
Print raster bit image
64
GS w
Set bar code width
65
BS F W
Download customized font
66
BS F R
Read customized font
67
BS F C
Clear customized font
68
BS F I
Transmit customized font information
69
BS M
Select device font type
70
BS V
Select cut mode and executes a partial/full
cut
71
BS W D
Define watermark image
72
BS W E
Select Watermark image
73
BS DC1 %
(fn = 1)
Select BIL(bixolon Interactive Linker)
function
74
BS DC1 %
(fn = 3)
Select reverse printing function

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
