BIXOLON SRP-F310 Command Manual

SRP-F310/312
Rev. 1.01 BIXOLON
- 7 -
2-2 Details of Control Commands
HT
Function :
Horizontal tab
Code :
ASCII
HT
Hex
09
Decimal
9
Range:
None
Default:
None
Description :
This command moves the print position to the next horizontal tab position. If the next horizontal tab position is not
specified, this command will be void.
Remarks :
■ The horizontal tab position is set by <ESC> D.
■ With the underline mode turned on, the underline printing is not applied to the tab space created by this command.
Differences:
None

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
