BIXOLON SRP-F310II Command Manual

SRP-F310/F312/F313II
ESC v
Function :
Transmit paper sensor status
Code :
ASCII
ESC
v
Hex
1B
76
Decimal
27
118
Range :
None
Default :
None
Description :
■
This command transmits a byte of data specifying the paper sensor status.
■ The status of paper near end and paper end sensors is sent to the host as follows :
• When paper near end is detected, 0x03 is transmitted.
• When paper end is detected, 0xC is transmitted.
Remarks :
■
The paper sensor status can be transmitted using GS r.
■ The near end senor is optional while paper end sensor required.
■
If the printer is not equipped with a near end sensor, the paper near end sensor is considered as normal condition.
Differences :
None
Rev. 1.00 BIXOLON
- 50 -

BIXOLON SRP-F310II Specifications

General

Print Method	Direct Thermal
Print Width	Up to 72 mm
Paper Thickness	0.06 ~ 0.08 mm
Weight	1.5 kg
Paper Loading	Easy Paper Loading
NV Image	Yes
Resolution	203 dpi
Interface	USB, Serial, Ethernet, Bluetooth
Paper Width	80 mm
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0 ~ 45 °C
Storage Temperature	-20 ~ 60 °C
Humidity	10% to 80% RH (non-condensing)
Emulation	ESC/POS
Receive Buffer	4 KB
