BIXOLON SRP-F310II Command Manual

SRP-F310/F312/F313II
ESC {
Function :
Turns upside-down printing mode on/off
Code :
ASCII
ESC
{
n
Hex
1B
7B
n
Decimal
27
123
n
Range :
0 ≤ n ≤ 255
Default :
n = 0
Description :
■
This command selects/deselects upside-down printing mode according to the least significant bit as follows.
LSB
Upside-down mode
0
Turned off
1
Turned on
Remarks :
■ This command is valid only when entered at the beginning of the line.
■ The upside-down print mode has no effect in page mode. If this command is processed in page mode, upside-down
printing mode is enabled when the printer returns to standard mode.
■ 180 rotated characters are printed from right to left in upside-down print mode.
■ The setting of this command remains effective until ESC !, ESC @, printer reset or power cycling is executed.
Example
Normal Upside- down Mode
Differences :
None
Rev. 1.00 BIXOLON
- 51 -

BIXOLON SRP-F310II Specifications

General

Print Method	Direct Thermal
Print Width	Up to 72 mm
Paper Thickness	0.06 ~ 0.08 mm
Weight	1.5 kg
Paper Loading	Easy Paper Loading
NV Image	Yes
Resolution	203 dpi
Interface	USB, Serial, Ethernet, Bluetooth
Paper Width	80 mm
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0 ~ 45 °C
Storage Temperature	-20 ~ 60 °C
Humidity	10% to 80% RH (non-condensing)
Emulation	ESC/POS
Receive Buffer	4 KB
