◈ Specifications
Item Details
Printing Method Thermal Line Printing
Dot Density 203 x 203 Dpi (8 dot/mm)
Printing Width 48mm
Characters per
line
32 (Font A : 12x24)
42 (Font B : 9x24)
Printing Speed
*1)
Approximately 1.97 inches/sec
50 mm/sec
at 25℃/printing duty 12.5%
Receive Buffer
Size
15K bytes
SMPS Input
Voltage
100 ~ 240 VAC
Temperature
5 ~ 40℃ (Operating)
-10 ~ 50℃ (Storage)
Environmental
Conditions
Humidity
30 ~ 80% RH (Operating)
10 ~ 90% RH (Storage)
Mechanism 30,000,000 line
Printer
MCBF *2)
Head 100km
Paper Width 58.0±0.5mm
Paper Thickness Paper thickness : 0.062 ~ 0.075 mm
Roll Diameter Ø60 mm
Paper
Paper Tube
Inner : Ø12mm (0.47”)
Outer : Ø18mm (0.71”)
※ Note
*1) Printing speed may be slower depending on the data transmission
speed and the combination of control commands.
*2) The above values are calculated under printing level 2 with
recommended paper at normal temperature.
The values may vary with environment temperature, printing level,
etc.
◈ Serial(RS-232C) Fixed Interface Model Windows
Driver Installation
1. After running the product installation CD, run the Thermal Printer >
STP-103 > Drivers > Windows Driver > Drivers Folder > Win
STP-103_Vx.x.x.exe file.
2. In the opening installation window, click on Next.
3. In the Ready to Install the Program window, click on Install.
4. In the Select Port Type window, select one Serial Port and click
Next.
5. In the Question window, select Yes and the computer will reboot.
6. After rebooting, open Start > Settings > Printers & Fax > BIXOLON
STP-103 Icon > Right-Click > Properties.
7. In the Properties window, select the Port tab and click on the Port
Settings. Check to see that the information is identical to the self-test
results after installation.
8. In the Properties window, after selecting the General tab, click on
Print Test Page to confirm that printing is normal.
◈ Parallel (IEEE1284) Fixed Interface Model
Windows Driver Installation
1. After running the product installation CD, run the Thermal Printer >
STP-103 > Drivers > Windows Driver > Drivers Folder > Win
STP-103_Vx.x.x.exe file.
2. In the opening installation window, click on Next.
3. In the Ready to Install the Program window, click on Install.
4. In the Select Port Type window, select one Parallel Port and click
Next. (Refer to Figure 1.)
5. In the Question window, select Yes and the computer will reboot.
6. After rebooting, open Start > Settings > Printers & Fax > BIXOLON
STP-103 Icon > Right-Click > Properties.
7. In the Properties window, after selecting the General tab, click on
Print Test Page to confirm that printing is normal.
◈ WEEE (Waste Electrical and Electric Equipment)
This marking shown on the product or its literature, indicates that
is should not be disposed with other household wastes at the end
of its working life, To prevent possible harm to the environment
or human health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle it responsibly
to promote the sustainable reuse of material resources. Household
users should contact either the retailer where they purchased this
product, or their local government office, for details of where and
how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms
and conditions of the purchase contract. This product should not
be mixed with other commercial wastes for disposal.
☎ BIXOLON Co., Ltd.
● Website http://www.bixolon.com
● Headquarters
(Add) A-502, Digital Empire, 980-3 Yeongtong-dong,
Yeongtong-gu, Suwon-si, South Korea, 443-813
(Tel) +82-31-218-5531
● U.S. Office
(Add) 1210 E. 223rd St., #330, Carson, CA 90745
(Tel) +1-858 764 4581
● Europe Office
(Add) BIXOLON Europe GmbH, Lindenstrasse 169,
40233 Dusseldorf, Germany
(Tel) +49 (0)211 68 78 54 0
