Instruction manual GSP Technical data
38107010002 en-US 77 / 92
Dimensions Notes
Dimensions packaging
(L x W x H)
820 x 700 x 823 mm / 32.3" x
27.6" x 32.4"
Weight Approx. 43 kg / 94.8 lb
approx. 50 kg / 110.2 Ib with packaging
Types of current, voltages,
power consumption
See identification plate
9.2 Dimensions GSP H with a carriage inclination of 18°
Fig.111: GSP H 18° L
Dimensions Notes
Installation area (L x W) 532 x 478 mm / 20.9" x 18.8"
Maximum dimensions
(L x W x H)
801 x 751 x 562 mm / 31.5" x
29.6" x 22.1"
The work area of the ma-
chine includes the area
within the max. dimensions:
IP rating IP33
Product size Height: 188 mm / 7.4"
Width: 290 mm / 11.4"
Round: Ø 235 mm / 9.3"
Depositing height 62 mm
Slice thickness 0 - 24 mm / 0 - 0.9"
0 - 3 mm / 0 - 0.1"
Infinitely adjustable
Fine adjustment
Blade diameter 330 mm / 13.0"
