• The label on your tool may include the following symbols. The symbols and their
definitions are as follows:
V..................volts A ..................amperes
Hz................hertz W..................watts
min ..............minutes ................alternating current
............direct current
n
o ................no load speed
................Class I Construction ..................earthing terminal
(grounded) ................safety alert symbol
................Class II Construction …/min ..........revolutions or reciprocation
(double insulated) per minute
FUNCTIONAL DESCRIPTION
Figure A
1. Trigger Switch
2. Forward/Reverse Button
3. Dual Range Gearing
4. Torque Adjust Collar
5. Keyless Chuck
6. Battery Compartment
7. Battery Release Button (on
battery)
3
1
2
4
5
6
7
A
C
D
E
B
