ENGLISH • 29
SERVICE INFORMATION
Black & Decker offers a full network of company-owned and
authorized service locations. All Black & Decker Service
Centers are staffed with trained personnel to provide
customers with efficient and reliable power tool service.
For more information about our authorized service centers
and if you need technical advice, repair, or genuine factory
replacement parts, contact the Black & Decker location
nearest you, or visit us at www.BlackandDecker-la.com
TROUBLESHOOTING
Problem Cause Solution
The LED indicator does not illuminate
when the charging cable is connected to
the battery.
Loose connection at the
connection terminals.
Check the connection.
No AC power at outlet Ensure power is present at outlet.
Overheating shutdown
Clean dirty ventilation openings or remove
objects covering the unit. Place the unit in a
cooler location.
Short circuit shutdown
Disconnect the cables, and check the power
circuit is right.
The green LED light stays on even when
batteries are not full.
The battery voltage is
too low.
Check the battery voltage with a multimeter.
Recycle the battery if the battery voltage is
too low.
The battery clips are not
connected properly to
the battery terminals.
Check the connection and re-attach the clips
to the terminals.
The red LED light turns on. reverse polarity Check the polarity
SPECIFICATIONS
Rated voltage
AR 220V AC/ 50Hz
B2C 220V AC/ 50-60Hz
B3 120V AC/ 60Hz
B2 220V AC/ 60Hz
BR 127V AC/ 60Hz
Input current 5A
Maximum output current 40±4A
Continuous output voltage 14.8±0.3V DC
Constant current output voltage <14.8VDC
Floating charging voltageo 13.6±0.3VDC
The lowest voltage for the
charger to start to working 2.5V
Battery type 12V lead-acid battery
Ambient temperature 32ºF~104 (0ºC~40ºC)
Weight 7.9 lb. (3600 g)
Dimension (L×W ×H) 13.8 × 9.37 × 5.9 in
(350.6 × 238 × 151 mm)
