Black & Decker BCCS320 User Manual

15
ENGLISH
Repairs
The charger and batteries are notserviceable. There are no
serviceable parts inside the charger or batterypack.

WARNING: To assure product SAFETY and RELIABILITY,
repairs, maintenance and adjustment (including brush
inspection and replacement, when applicable) should
be performed by a BLACK+DECKER factory service
Saw Chain Sharpening (Fig.N - P)

CAUTION: Sharp chain. Always wear protective gloves
when handling the chain. The chain is sharp and can
cut you when it is notrunning.

WARNING: Sharp moving chain. To prevent accidental
operation, ensure that battery is removed from the tool
before performing the following operations. Failure to
do this could result in serious personalinjury.

WARNING: Do not over file chain rakers, this will
increase the risk of kickback. If the chain has been
sharpened more than four times, replaceit.
Each time the chain is sharpened, it loses some of the low
kickback qualities and extra caution should beused.
It is recommended that a saw chain be sharpened no more
than fourtimes.
NOTE: The cutters will dull immediately if they touch the
ground/dirt or a nail whilecutting.
To get the best possible performance from your pruner it is
important to keep the teeth of the saw chain sharp. Follow
these helpful tips for proper saw chain sharpening:
1. For best results use a 11/64" (4.5mm) file and a file holder
or filing guide to sharpen your saw chain. This will ensure
you always get the correct sharpeningangles.
2. Place the file holder flat on the top plate and depth
gauge of thecutter.
3. Keep the correct top plate
25
filing angle line of 30° on
your file guide parallel with your chain (file at 60° from
chain viewed from the side) as shownin Fig. N.
4. Sharpen cutters on one side of the chain first. File from
the inside of each cutter to the outside. Then turn your
saw around and repeat the processes (2, 3, 4) for cutters
on the other side of thechain.
NOTE: Use a flat file to file the tops of the rakers (portion
of chain link in front of the cutter) so they are about .025"
(.635 mm) below the tips of the cutters as shownin Fig. O.
5. Keep all cutter lengthsequal as shownin Fig. P.
6. If damage is present on the chrome surface of the
top plates or side plates, file back until such damage
isremoved.

CAUTION: After filing, the cutter will be sharp, use extra
caution during thisprocess.
BLACK+DECKER recommended accessories should be
used with thisproduct.
Recommended accessories for use with your product
are available at extra cost from your local dealer or
authorized service center. If you need assistance in
locating any accessory, please contact BLACK+DECKER call
1-800-544-6986
Accessories

WARNING: Since accessories, other than those offered
by BLACK+DECKER , have not been tested with this
product, use of such accessories with this product
could be hazardous. To reduce the risk of injury, only
Sprocket and Sprocket Cover (Fig.D - G)

CAUTION: Sharp chain. Always wear protective gloves
when handling the chain. The chain is sharp and can
cut you when it is notrunning.

WARNING: Sharp moving chain. To prevent accidental
operation, ensure the battery is removed from the
tool is unplugged before performing the following
operations. Failure to do this could result in serious
personalinjury.
1. Place the saw on a flat, firmsurface.
2. Remove sprocket cover
8
as described in Installing the
Guide Bar and Saw Chainsection.
3. Wearing protective gloves, use a clean, soft bristle brush
to wipe away any saw dust, sticks, vines or other debris
that may have collected inside the sprocket cover and
around the chain
5
or sprocket
17
.
4. Rotate the chain tension screw
10
using the flat
screwdriver end of thewrench
12
. Turning the screw
counterclockwise allows the guide bar
4
to recede
and reduces the tension on the chain so that it may
beremoved.
5. Wearing protective gloves, grasp the saw chain and
guidebar and lift them away from the tool.
6. Wearing protective gloves, use a clean, soft bristle brush
to wipe away any saw dust or other debris that may have
collected on the guide bar and around the chain.
7. Install the chain, guide bar and sprocket cover as
described in Installing the Guide Bar and Saw
Chain, Replacing the Saw Chainsections and adjust
chain tension properly before use as described in
theAdjustingChain Tensionsection.
Saw Chain and Guide Bar
After every few hours of use, remove the sprocket cover,
guide bar and chain and clean thoroughly using a soft bristle
brush.
Cleaning

WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk
of eye injury, always wear ANSI Z87.1 approved eye
protection when performing thisprocedure.

WARNING: Never use solvents or other harsh
chemicals for cleaning the non‑metallic parts of the
tool. These chemicals may weaken the plastic materials
used in these parts. Use a cloth dampened only with
water and mild soap. Never let any liquid get inside the
tool; never immerse any part of the tool into aliquid.
Your BLACK+DECKER power tool has been designed to
operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends
upon proper tool care and regularcleaning.

Black & Decker BCCS320 Specifications

General

Brand	Black & Decker
Model	BCCS320
Category	Chainsaw
Language	English
