Black & Decker BDUR1 - Reassembling Floor Brush Assembly

19MAINTENANCE
Slide the right side of the brush bar
roller into the guides as shown.
Replace the brush bar roller base
plate as shown.
Replace the screws that hold the
brush roller base plate in place as
shown.
7
7
8
8
9
9
