Warning! Only use the charger provided to charge
CS3651LC.
Warning! Do not charge the battery at ambient tempera-
tures below 10 °C or above 40 °C.
Selecting the direction of rotation (g. D)
For drilling and for tightening screws, use forward rotation.
For loosening screws or removing a jammed drill bit, use
reverse rotation.
u To select forward rotation, push the forward/reverse
slider (2) to the forward position.
u To select reverse rotation, push the forward/reverse
slider (2) to the rearward position.
u To lock the tool, set the forward/reverse slider into the
centre position.
Drilling/screwdriving
u Select forward or reverse rotation using the forward/
reverse slider (2).
u To switch the tool on, press the on/off switch (1).
u To switch the tool off, release the on/off switch (1).
LED work light
The LED work light (4) is activated automatically when the
trigger is depressed. The LED will also illuminate when the
trigger is depressed and the forward/reverse slider (2) is in
the locked off position (central position).
Hints for optimum use
Screwdriving
u Always use the correct type and size of screwdriver
bit.
u If screws are difcult to tighten, try applying a small
amount of washing liquid or soap as a lubricant.
u Use the spindle lock to loosen very tight screws or to
rmly tighten screws.
u Always hold the tool and screwdriver bit in a straight
line with the screw.
u When screwing in wood, it is recommended to drill a
pilot hole with a depth equal to the length of the screw.
A pilot hole guides the screw and prevents splintering
or distortion of the wood. For the optimum size of the
pilot hole, refer to the table below.
u When screwing in hardwood, also drill a clearance
hole with a depth equal to half the length of the screw.
For the optimum size of the clearance hole, refer to
the table below.
Screw size
Pilot hole ø
(softwood)
Pilot hole ø
(hardwood)
Clearance
hole
No. 6 (3.5 mm) 2.0 mm 2.5 mm 3.6 mm
No. 8 (4 mm) 2.5 mm 3.0 mm 4.5 mm
No. 10 (5 mm) 3.0 mm 3.5 mm 5.0 mm
Drilling pilot holes
u Always apply a light pressure in a straight line with the
drill bit.
u Just before the drill tip breaks through the other side of
the workpiece, decrease pressure on the tool.
u Use a block of wood to back up workpieces that may
splinter.
u Make an indentation using a centre punch at the
centre of the hole to be drilled in order to improve
accuracy.
Accessories
The performance of your tool depends on the accessory
used. BLACK+DECKER and Piranha accessories are
engineered to high quality standards and designed to
enhance the performance of your tool. By using these
accessories you will get the very best from your tool.
This tool uses screwdriver bits with a 1/4" (6.35 mm)
hexagonal shank. Piranha Super-lok accessories are
designed for use with this tool.
