Black & Decker EGBL108 User Manual

8
ENGLISH
(Original instructions)
Technical data
EGBL108 (H1)
Voltage V
DC
10.8
No-load speed Min
-1
0-600
Max. torque Nm 12/24
Chuck capacity mm 10
Max Drilling capacity
Steel/wood mm 10/25
Charger 905599** typ. 1
Input Voltage V
AC
230
Output Voltage
V
DC
10.8
Current mA 330
Approx. charge time h
3 - 5
Battery BL1110
BL1310 BL1510
Voltage V
DC
10.8 10.8 10.8
Capacity Ah 1.1 1.3 1.5
Type Li-Ion Li-Ion Li-Ion
Level of sound pressure according to EN 60745:
Sound pressure (L
pA
) 68 dB(A), uncertainty (K) 3 dB(A)
Sound power (L
WA
) 79 dB(A), uncertainty (K) 3 dB(A)
Vibration total values (triax vector sum) according to EN 60745:
Drilling into metal (a
h, D
) < 2.5 m/s
2
, uncertainty (K) 1.5 m/s
2
Screwdriving without impact (a
h, s
) < 2.5 m/s
2
, uncertainty (K) 1.5 m/s
2
EC declaration of conformity
MACHINERY DIRECTIVE
%
EGBL108
Black & Decker declares that these products described under
"technical data" are in compliance with:
2006/42/EC, EN 60745-1, EN 60745-2-1
For more information, please contact Black & Decker at the
following address or refer to the back of the manual.
The undersigned is responsible for compilation of the technical
le and makes this declaration on behalf of Black & Decker.
_
Kevin Hewitt
Vice-President Global Engineering
Black & Decker Europe, 210 Bath Road, Slough,
Berkshire, SL1 3YD
United Kingdom
12/04/2010

Black & Decker EGBL108 Specifications

General

Soft grip	Yes
Chuck type	Keyless
Product design	Pistol grip drill
Vibration emission	2.5 m/s²
Product color	Black, Orange
Number of clutch settings	11
Torque (max)	24 N⋅m
Number of gears	1
Sound power level	68 dB
Chuck capacity (max)	10 mm
Sound pressure level	79 dB
Idle speed (1st gear)	600 RPM
Drilling diameter in wood (max)	25 mm
Power source	Battery
Battery voltage	10.8 V
Battery capacity	1.5 Ah
Battery technology	Lithium
