9
ENGLISH
(Original instructions)
Troubleshooting
If your tool seems not to operate properly, follow the instruc-
tions below. If this does not solve the problem, please contact
your local Black & Decker repair agent.
Warning! Before proceeding, unplug the tool.
Tool runs slowly
u Check that the spool housing can rotate freely. Carefully
clean it if necessary.
u Check that the cutting line does not protrude more than
11 cm from the spool housing. If it does, cut it off so that it
just reaches the line trimming blade.
Automatic line feed does not work
u Keep the tabs depressed and remove the spool cover
from the housing.
u Pull the cutting line until it protrudes 11 cm from the hous-
ing. If insufcient cutting line is left on the spool, install a
new spool of cutting line as instructed above.
u Align the tabs on the spool cover with the cut outs in the
housing.
u Push the cover onto the housing until it snaps securely
into place.
u If the cutting line protrudes beyond the trimming blade, cut
it off so that it just reaches the blade.
If the automatic line feed still does not work or the spool is
jammed, try the following suggestions:
u Carefully clean the spool cover and housing.
u Remove the spool and check if the lever can move freely.
u Remove the spool and unwind the cutting line, then wind it
on neatly again as described above. Replace the spool as
instructed.
Protecting the environment
Z
Separate collection. This product must not be
disposed of with normal household waste.
Should you nd one day that your Black & Decker product
needs replacement, or if it is of no further use to you, do not
dispose of it with household waste. Make this product avail-
able for separate collection.
z
Separate collection of used products and packag-
ing allows materials to be recycled and used again.
Re-use of recycled materials helps prevent
environmental pollution and reduces the demand
for raw materials.
Local regulations may provide for separate collection of elec-
trical products from the household, at municipal waste sites or
by the retailer when you purchase a new product.
Black & Decker provides a facility for the collection and
recycling of Black & Decker products once they have reached
the end of their working life. To take advantage of this service
please return your product to any authorised repair agent who
will collect them on our behalf.
You can check the location of your nearest authorised repair
agent by contacting your local Black & Decker ofce at
the address indicated in this manual. Alternatively, a list of
authorised Black & Decker repair agents and full details of our
after-sales service and contacts are available on the Internet
at: www.2helpU.com
Technical data
GL7033
(Type 1)
GL8033
(Type 1)
GL9035
(Type 1)
Voltage V
AC
230 230 230
Power input W
700 800 900
No-load speed min
-1
7000 7000 7000
Weight
kg 3.2 3.2 3.2
Level of sound pressure:
Sound pressure (L
pA
) 80 dB(A), uncertainty (K) 2 dB(A)
Sound power (L
WA
) 94 dB(A), uncertainty (K) 2 dB(A)
Vibration total values (triax vector sum) according to EN 786:
Vibration emission value (a
h
) 8.2 m/s
2
, uncertainty (K) 1.5 m/s
2

Black & Decker GL7033 Specifications

General

Power source	Electric AC
Line diameter	2 mm
Product color	Black, Red
Plant protector	Yes
Rotational speed	7000 RPM
Height adjustment	100 mm
Line length supplied	10 m
Cutting diameter (max)	330 mm
Quantity per pack	1 pc(s)

Weight and Dimensions

Weight	3200 g
