3
OPERATING INSTRUCTIONS
To turn the cordless spotlight on depress the Trigger Switch. Depressing the Trigger
Switch at one-second intervals advances the brightness level from dim to brightest.
To lock the trigger into the ON position pull the Trigger Switch and move the Trigger
Switch Lock down. This will lock the trigger into the ON position. To shut it off, simply
move the Trigger Switch lock up to the OFF position.
PERIODIC MAINTENANCE
All batteries lose charge with time, especially when they are warm. AC recharge is
recommended every two months, when not in frequent use. Use the AC recharger and
charge for the recommended time. If the unit gets dirty, gently clean the outer surfaces
of the spotlight unit with a soft cloth moistened with a mild solution of water and
detergent. Periodically inspect the condition of the recharge adapters, connectors and
wires. Replace any components that may have become worn or broken.
RECHARGING THE SPOTLIGHT
Charging From a 120 Volt AC Source
To recharge, plug a 120 volt AC household extension cord into the 120 volt AC
Recharger on the back of the unit and charge for 12-14 hours or until the green
Battery Charge Level Indicator LED lights.
Charging From a 12 Volt DC Source
Plug the DC fused Recharge/Power Adapter (included) into the Recharge Port.
RECHARGE PORT
BUILT-IN 120V AC
CHARGER
BATTERY CHARGE
LEVEL INDICATOR
HOUSEHOLD EXTENSION CORD
(NOT INCLUDED)
TRIGGER SWITCH
TRIGGER SWITCH
LOCK
2
3/4 View
Back View
12 Volt DC Charging Adapter
BUILT-IN
120 VOLT AC
CHARGER
SMART
ELECTRONIC
DIMMER
SWITCH
RUBBER BEZEL
CARRY
LANYARD
DC RECHARGING
PORT
TRIGGER SWITCH
LOCK
PISTOL GRIP HANDLE
QUARTZ HALOGEN
BULB
