31
CHAPTER 2: Quick Start
2.8 Two Types of Bell 208 Operation
Two Bell 208 Quick Setups are
available, as shown in Table 2-1.
One configures the modem for
Bell 208 operation, exclusively;
the other configures the modem
for V.32/208 auto-detect mode.
2.8.1 B
ELL
208 O
PERATION
(E
XCLUSIVE
)
The Quick Setup identified on the
LCD as 2-W DIAL (208) configures
the modem for 2-wire dial
synchronous operation compatible
with Bell standard 208B. The data
rate is fixed at 4800 bps, and the
data format is set to synchronous.
Both connected modems must be
set for 208B operation.
Beginning with the section titled
“Answering a Call Automatically,”
all information in Section 2.4.3 also
applies to Bell 208 operation.
Fig. 2-3. Quick Setup.
QUICK SETUP <10>
2-W DIAL (208)
QUICK SETUP <11>
2-W DIAL V32/208
