Table 1-1. Pin Assignments—EIA Interface Connector (continued)
Pin Designation Function LCD Indicator Source
22 CE Ring indicator (RI) R Modem
23 CH Speed select DTE
24 DA External transmit clock DTE
25 CN Test mode indicator (TM) TM Modem
