Max Express Ethernet Switch LB9217A-R2 & Applicable Modules
16
Port Settings
The duplex mode and speed can be altered and the flow control can be turned
on/off to accommodate special needs.
Follow these steps to change the speed/duplex mode setting or to toggle flow
control ON/OFF:
y Move the cursor to MODE column to change the speed/duplex mode setting, or
move the cursor to FLW column to change the flow control setting
y Move the cursor and select a port
y Press [SPACE] and select a desired setting from the list that appears on the
screen
y Press [ENTER] to apply and save the setting
FX Ports
The port setting for the fiber module is slightly different from the TX port.
Consult the following table for a brief description on FX ports:
Table 4: Mode Setting on FX Ports
Communication Mode Description
Flow control Always N (off) and can not be changed
100FD 100Mbps at full duplex mode
100HD 100Mbps at half duplex mode
TX Ports
Consult the following table for a brief description on TX ports:
Table 5: Mode Setting on TX Ports
Communication Mode Description
Flow control on / off Y (on) / N (off)
Auto Auto-Negotiation
100FD 100Mbps at full duplex mode
100HD 100Mbps at half duplex mode
10FD 10Mbps at full duplex mode
10HD 10Mbps at half duplex mode
