OVERVIEW
11
Figure 1 USB Micro Extender System
Local Video Outputs
Dual Video Support
ACU4201A, ACU4222A only
Serial and Audio
Transmission
ACU4222A only
USB and Video extension over
CATx cables up to 150ft (50m).
Local Unit
Remote Unit
CPU
USB Devices
5V PSU
Remote Console
