Appendix B: Rack Mount Options
All USB Micro Extender units can be mounted in a 19” rack in any combination using the
mounting kit: RMK19U-X3
RMK19U-X3 Mounting Kit
This mounting kit allows you to mount up to three units across 1U. It contains one rack plate
and M3 countersunk mounting screws.
To mount a unit:
1. Remove the feet from the extender unit.
2. Align the holes on the base plate with the vacant screw holes on the base of the extender
unit.
3. Fasten the base of the unit to the plate of the mounting kit using the supplied screws.
Figure 9 RMK19U-X3 Mounting Kit
