16
3. Installation
For first-time users, we recommend that you carry out a test placement, confined to a single
room, before commencing full installation. This will allow you to identify and solve any
cabling problems, and experiment with the USB extender system more conveniently.
3.1 Package Contents
You should receive the following items in your extender package. If anything is missing,
please refer to Appendix F to obtain Technical Support.
• Extender Remote unit.
• 5-VDC universal power supply for Remote unit.
• Extender Local unit.
• USB/Video CPU cable (1.0m) with USB connector and VGA video (HD15 M-F)
connector.
• CPU video cable (1.0m) with VGA video (HD15 M-F) connector.
Models: ACU4201A and ACU4222A only.
• Serial cable (DB9 M-F connectors, 1:1 connections).
Models: ACU4222A only.
• Two stereo audio cables (3.5mm stereo plugs).
Model: ACU4222A only.
• IEC AC Power Cord.
• User Guide.
