9
CHAPTER 1: Specifications
Connectors — ACU5010A transmitter:
(1) Left-side-mounted DB25 female for CPU
connection;
(1) Left-side mounted 8-pin mini-DIN female
expansion port for future features;
(1) Right-side-mounted RJ-45 for CAT5 link to
transmitter;
ACU5010A receiver, ACU5011A:
(2) Left-side-mounted 6-pin mini-DIN female, (1) for
keyboard and (1) for mouse;
(1) Left-side-mounted HD15 female for monitor;
(1) Right-side-mounted RJ-45 for CAT5 link to
receiver;
(1) Right-side-mounted 2.5-mm center-positive barrel
jack for power input;
Maximum
Altitude — 10,000 ft. (3048 m)
Temperature
Tolerance — 32 to 104˚F (0 to 40˚C)
Humidity
Tolerance — 5 to 60% noncondensing
Enclosure — Steel and stainless steel
Power — ACU5010A transmitter: 5 VDC at 500 mA (normally
draws only 180 mA) from attached CPU’s keyboard
interface;
ACU5010A receiver or ACU5011A using included
external power adapter:
Input: 100 to 240 VAC at 50 to 60 Hz from utility-power
(mains) outlet, through detachable power cord and
IEC 320 inlet, to external transformer;
Output: 5 VDC at up to 2.5 A from transformer to
receiver’s 2.5-mm barrel jack (receiver normally
draws less than its rated 500 mA);
ACU5010A receiver or ACU5011A using PS5000: 5 VDC
at 500 mA from PS5000 to receiver’s 2.5-mm barrel
jack;
