8
SERVSWITCH™ WIZARD EXTENDER
1. Specifications
Cable Required — Between transmitters and receivers: Four-pair (eight-
wire) Category 5 or higher unshielded twisted-pair
(UTP); shielded twisted-pair (STP) can also be used at
shorter distances
Compliance — CE (EN55022 Class A); FCC Part 15 Subpart B Class A,
IC Class/classe A
Standards — VGA, SVGA, XGA, or XGA-2 video
Interfaces — Video: VGA;
Keyboard and mouse: IBM PS/2 compatible
Resolution and
Refresh Rate — At distances to 65 m (210 ft.): Up to 1600 x 1280
noninterlaced at up to 85 Hz;
At distances to 100 m (325 ft.): Up to 1600 x 1280
noninterlaced at up to 65 Hz;
At distances to 200 m (655 ft.): Up to 1024 x 768
noninterlaced at up to 65 Hz
Maximum
Distance — Between transmitters and receivers: Up to 200 m (655 ft.)
of unshielded twisted-pair cable or 100 m (325 ft.) of
shielded twisted-pair cable;
From ACU5010A transmitter: 5 m (15 ft.) to any attached
CPU;
From ACU5010A receiver or ACU5011A: 10 m (30 ft.) to
any attached keyboard, monitor, or mouse;
User Controls — Keyboard commands;
ACU5010A transmitter, ACU5010A receiver, ACU5011A:
(1) Rear-mounted 4-position DIP switch for various
options and functions
Indicators — ACU5010A transmitter, ACU5010A receiver, ACU5011A:
Right-side-mounted LED for power and data activity
