25
CHAPTER 3: Installation
Figure 3-4. A simplified ACU5011A Wizard Extender receiver installation.
Receiver
Remote
user #1
Optional local
user #1
Local user #2
Local users’ monitors, keyboards, and mice
plug in directly or with extension cables
ServSwitch Duo (KV6108SA)
Computer CPUs connected with EHN408 cables
Keyboard, mouse,
and monitor plug in
directly or with
extension cables
(see the Appendix)
CAT5 or higher
cable, up to
200 m (655 ft.)
