Black Box Switch User Manual

3 of 3
TECH SPECS
Connectors — SW034A-FFF: DB9 F;
SW044A: DB15 F;
All others: DB25 F
Size — Chassis Style A: 2.5"H x 6"W x 6.3"D (6.4 x 15.2 x 16 cm);
Chassis Style B: 3.5"H x 6"W x 6.3"D (8.9 x 15.2 x 16 cm)
Weight — 1.5 lb. (0.7 kg)
6/14/2007
#10140
