Black Stone 1891 - Assembly Guide; Exploded View; Illustrated Parts List

ASSEMBLY GUIDE
ILLUSTRATED PARTS LIST
1 Body (1 piece) 2 Griddle Top and Hood (1 piece) 3 Side Shelf (1 piece)
4 Handle (1 piece) 5 Legs (1 piece) 6 Regulator (1 piece)
7 Grease cup (1 piece) 8 Griddle feet (4 pieces) 9 M6 Bolts (2 pieces)
10 M8 Flange nuts (4 pieces) NOT INCLUDED - LP Gas Bottle
EXPLODED VIEW
PARTS
QTY
1.1
Bottom Panel
1
1.2
Bae Panel
1
1.3
Gas Rail
1
1.4
Ignition Needles
2
PARTS
QTY
1.5
H Burners
2
1.6
Knob Bezels
2
1.7
Control Knobs
2
2.1
Hood
1
PARTS
QTY
2.2
Hood Hinges
2
2.3
Griddle Top
1
5.1
Upper Right Leg
Assembly
1
5.2
Upper Le Leg Assembly
1
PARTS
QTY
5.3
Lower Legs
4
5.4
Leg Thumbscrews
4
5.5
Leg Caps
4
5.6
Locking Pin Assembly
2
4
2.1
2.2
2.3
6
8
1.1
1.2
1.3
1.4
1.5
1.6
1.7
5
7
1
5.6
5.1
5.2
5.3
5.4
5.5
3
Model 1891 | Owner’s Manual | | Owner’s Manual | Model 1891
06 07
Assembly Guide Assembly Guide
