Black Stone 1940 - Griddle Assembly Instructions; Installing Wheels, Braces, and Hanger

To Next Page

To Previous Page

STEP 

Install the upper leg brace between the upper right legs with

four (4) M6x12 screws. (Do not tighten these screws yet.)

STEP 

Install the wheels on

the lower right legs.

STEP 

Install the two lower leg braces between the lower le and

right leg connections with eight (8) M6x35 screws. (Do not tighten these

screws yet.)

STEP 

Install the upper propane hanger to the upper right leg brace

with the M6x16 screw and M6 locknut.

Model 1940 | Owner’s Manual | | Owner’s Manual | Model 1940

10 11

Assembly Guide Assembly Guide
