ASSEMBLY GUIDE
ILLUSTRATED PARTS LIST
ENGLISH
TOOLS NEEDED: Phillips head screwdriver
& Adjustable wrench
TOOL NEEDED:
Phillips head screwdriver
TOOL NEEDED:
Adjustable wrench
TOOLS NEEDED: Phillips head screwdriver
& Adjustable wrench
ENGLISH
NOT INCLUDED:
20 lb (9 kg) LPG tank & AA Battery
NOT INCLUDED:
20 lb (9 kg) LPG tank
NOT INCLUDED:
20 lb (9 kg) LPG tank & AA Battery
NOT INCLUDED:
20 lb (9 kg) LPG tank
NOT INCLUDED:
AA Battery
NOT INCLUDED:
1 lb (453 g) LPG bottle
NOT INCLUDED:
1 lb (453 g) LPG bottle
1 Body (1 piece) 2 Griddle top
& Hood (1 piece)
3 Faceplate
(1 piece)
4 Lower leg
assembly (1 piece)
5 Upper legs
(2 pieces)
6 Side handle
(1 piece)
7 Side shelf
(1 piece)
8 Grease cup
(1 piece)
9 Hood
handle (1 piece)
10 Regulator
(1 piece)
11 Wheels
(2 pieces)
12 Hardware pack (1 piece)
a. M6x12 bolts (30 pieces)
b. Control knobs (2 pieces)
c. M10x17 step bolts (2 pieces)
Bolt sleeves (2 pieces)
d. Self-tapping screws (2 pieces)
e. M6x12 hexagon bolts (4 pieces)
12a
12b
12c
12d 12e
Model 2015
04
Assembly Guide
