Black Stone 2020 - Page 8

ENGLISH
BLACKSTONEPRODUCTS.COM/SUPPORT
OWNER’S MANUAL | ASSEMBLY GUIDE
Make sure the front pins are
seated in the holes, then push
the griddle top back.
❶❶
Place the two front pins into
the front locking holes and push
the griddle top back.
❷❷
Then, set the two rear pins
into the rear holes.
❶
❶
Place the two front pins into
the front locking holes and push
the griddle top back.
❷
❷
Then, set the two rear pins
into the rear holes.
Make sure the front pins are
seated in the holes, then push
the griddle top back.
Make sure the front pins are fully
seated in the holes, then push
the griddle top forward to lock
the griddle in place.
Make sure the front pins are fully
seated in the holes, then push
the griddle top forward to lock
the griddle in place.
MODEL: 
STEP 07
Lift the side shelf handle and, while putting weight on the
fixed leg assembly crossbar, pull the griddle up and toward you until
the top of the wheeled leg assembly aligns with the C clamps.
STEP 08
Hang the grease cup on the back of the griddle body.
STEP 10
Use two (2) M6x12 bolts to secure the back of the griddle top
and hood to the back of the griddle body.
STEP 09
Place the griddle top and hood onto the griddle body by
aligning the four pins to the holes of the body.
lift and
lift and
pull
pull
place foot
place foot
here
here
❶
❶
❷
❷

