STEP 11
Use four (4) M5x10 screws [b.] to attach the top bracket to
the front-left and front-right legs, and secure the drawer heat shield
to the left and right drawer panels.
STEP 12
With the help of another person, set the griddle body on
its back and use fourteen (14) M6x15 screws [a.] to attach the griddle
cart to the griddle body.
STEP 13
With the help of another person, set the griddle on its feet.
Use four (4) M5x10 screws [b.] to attach the side panel with the
black plug to the rear-left leg and the front-left leg. (Note: the plug is
removable for future use if desired for gas hose routing.)
STEP 14
Use four (4) M5x10 screws [b.] to attach the other side panel
to the rear-right leg and front-right leg.
