Black Stone 6038 - Drop-in Installation Option

BLACKSTONEPRODUCTS.COM/SUPPORT
ENGLISH
| OWNER’S MANUALASSEMBLY GUIDE
Make sure the front pins are fully
seated in the holes, then push
the griddle top back to lock the
griddle in place.
Place the two front pins into the
front locking holes and push the
griddle top and hood back. Then,
set the two rear pins into the
rear holes.
Place the two front pins into the
front locking holes and push the
griddle top and hood back. Then,
set the two rear pins into the
rear holes.
Make sure the front pins are fully
seated in the holes, then push
the griddle top back to lock the
griddle in place.
Make sure the front pins are fully
seated in the holes, then push
the griddle top forward to lock
the griddle in place.
Make sure the front pins are fully
seated in the holes, then push
the griddle top forward to lock
the griddle in place.
MODEL: 
STEP 04
Remove the four (4) protective washers from the griddle foot
pins. With the help of another person, place the griddle top onto
the griddle body by aligning the four foot pins to the holes on top of
the unit.
OPTION A: INSTALL AS DROP-IN WITH
INSULATING JACKET
STEP 05
Slide the jacket left inner panel into the jacket left
outer panel.
STEP 06
Slide the jacket right inner panel into the jacket right
outer panel.
STEP 07
Place the jacket rear inner panel into the jacket rear
outer panel.
STEP 08
Place the jacket outer base panel onto the jacket inner
base panel.

