STEP 09
Use four (4) M6x35 screws [c.] to attach the left and right
jacket panel assemblies to the jacket base panel assembly.
STEP 10
Use six (6) M6x15 screws [b.] to attach the rear jacket panel
assembly to the jacket base panel assembly.
STEP 11
Use four (4) M6x45 screws [d.] to secure the rear jacket
panel to the left and right jacket panel assemblies.
Slide the jacket silicon sleeve into the jacket base panel assembly.
STEP 12
With the help of another person, direct the regulator hose
and electric wires through the jacket silicon sleeve and place the
griddle body onto the jacket base panel assembly.
[c.] × 4
[b.] × 6
[d.] × 4

