Black+Decker BCD003 User Manual

Problem Possible cause Possible solution
Unit shuts off
abruptly.
Battery pack has
reached its maximum
thermal limit.
Out of charge. (To maximize
the life of the battery pack
it is designed to shutoff
abruptly when the charge is
depleted
Allow battery pack to cool
down.
Place on charger
and allow to charge.
Maintenance
Your BLACK+DECKER tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regular cleaning.
Your charger does not require any maintenance apart from
regular cleaning.
@
Warning! Before performing any maintenance on
the tool, remove the battery from the tool. Unplug the
charger before cleaning it.
 Regularly clean the ventilation slots in your tool and
charger using a soft brush or dry cloth.
 Regularly clean the motor housing using a damp cloth.
Do not use any abrasive or solvent-based cleaner.
Protecting the environment
Z
Separate collection. Products and batteries
marked with this symbol must not be disposed of
with normal household waste.
Products and batteries contain materials that can be
recovered or recycled, reducing demand for raw materials.
Please recycle electrical products and batteries according
to local provisions. Further information is available at
www.2helpU.com
Technical data
BCD003
Voltage V
DC
18
No-load speed Min
-1
0 - 360/0 - 1400
Max. torque Nm 45
Chuck capacity mm 1-10
Max Drilling capacity
Steel/wood/Masonary mm 10/25/10
Weight kg 0.9
Charger 905902** 906349**
Input voltage V
AC
230 230
Output voltage V
DC
18 18
Current mA 400 1A
Approx. charge time Hours 3 - 5 1.5
Battery BL1518
Voltage V
AC
18
Capacity Ah 1.5
Battery BL1518
Type Li-Ion
Level of sound pressure according to EN 62841:
Sound pressure (L
pA
) 87.5 dB(A), uncertainty (K) 5 dB(A)
Sound power (L
WA
) 98.5 dB(A), uncertainty (K) 5 dB(A)
Vibration total values (triax vector sum) according to EN 62841:
Drilling into concrete (a
h, ID
) 14.2 m/s
2
, uncertainty (K) 1.5 m/s
2
Drilling into metal (a
h, D
) 1.1 m/s
2
, uncertainty (K) 1.5 m/s
2
EC declaration of conformity
MACHINERY DIRECTIVE
%
BCD003 Impact Drill
Black & Decker declares that these products described
under “technical data” are in compliance with:
EN62841-1:2015 , EN62841-2-1:2018.
These products also comply with Directive 2006/42/EC,
2014/30/EU and 2011/65/EU. For more information, please
contact Black & Decker at the following address or refer to the
back of the manual.
The undersigned is responsible for compilation of the technical
le and makes this declaration on behalf of Black & Decker.
Ed Higgins
Director – Consumer Power Tools
Black & Decker Europe, 270 Bath Road, Slough,
Berkshire, SL1 4DX, United Kingdom
20/11/2019
Guarantee
Black & Decker is condent of the quality of its products
and offers consumers a 24 month guarantee from the date
of purchase. This guarantee is in addition to and in no way
prejudices your statutory rights. The guarantee is valid within
the territories of the Member States of the European Union
and the European Free Trade Area.
To claim on the guarantee, the claim must be in accordance
with Black & Decker Terms and Conditions and you will need
to submit proof of purchase to the seller or an authorised
repair agent.
Terms and conditions of the Black & Decker 2 year guarantee
and the location of your nearest authorised repair agent
can be obtained on the Internet at www.2helpU.com, or by
contacting your local Black & Decker ofce at the address
indicated in this manual.
Please visit our website www.blackanddecker.co.uk to register
your new Black & Decker product and receive updates on new
products and special offers.
9
ENGLISH
(Original instructions)
