Black+Decker BDCDD12 Manual

10
ENGLISH
(Original instructions)
Vibration total values (triax vector sum)
according to EN 60745:
Drilling into metal (a
h, D
) <2.5 m/s
²
,
uncertainty (K) 1.5 m/s
²
,
Screwdriving without impact (ah) <2.5 m/s
²
,
uncertainty (K) 1.5 m/s
²
EC declaration of conformity
MACHINERY DIRECTIVE
BDCDD12 - Drill, Screwdriver
BLACK+DECKER declares that these
products described under "Technical data"
are in compliance with: 2006/42/EC,
EN 60745-1:2009 + A11:2010,
EN 60745-2-1:2010, EN 60745-2-2:2010
These products also comply with Directive
2004/108/EC (until 19/04/2016)
2014/30/EU (from 20/04/2016) and
2011/65/EU.
For more information, please contact
BLACK+DECKER at the following address or
refer to the back of the manual.
The undersigned is responsible for
compilation of the technical fi le and makes
this declaration on behalf of
BLACK+DECKER.
R. Laverick
Engineering Manager
BLACK+DECKER Europe, 210 Bath Road,
Slough,
Berkshire, SL1 3YD
United Kingdom
11.2015
90589867 Charger
Input voltage V
AC
230
Output voltage V
DC
10.8
Current mA 200
Approx. charge time Hours 8
90590287-02 Charger
Input voltage V
AC
230
Output voltage V
DC
10.8
Current mA 400
Approx. charge time Hours 3 - 5
90599854-06 Charger
Input voltage V
AC
230
Output voltage V
DC
10.8
Current Amp 1
Approx. charge time Hours 1.5
Battery
BL1512
Voltage V
AC
10.8
Capacity Ah 1.5
Type Li-Ion
Level of sound pressure according to EN 60745:
Sound pressure (L
pA
) 63 dB(A), uncertainty (K) 3 dB(A),
Sound power (L
WA
) 74 dB(A), uncertainty (K) 3 dB(A)
Technical data
Voltage V
DC
10.8
No-load speed Min
-1
0-550rpm
Max. torque Nm 12.5/26
Chuck capacity mm 1-10
Max Drilling capacity
Steel/wood mm 10/25
Weight kg 0.98
BDCDD12

Black+Decker BDCDD12 Specifications

General

Voltage	12V
Battery Type	Lithium-Ion
Weight	2.4 lbs
Power Source	Battery
Variable Speed	Yes
Chuck Size	3/8 inch
