Black+Decker BEH850 User Manual

4
ENGLISH
(Original instructions)
5
ENGLISH
(Original instructions)
Labels on tool
The following pictograms are shown on the tool along with the
date code:
:
Warning! To reduce the risk of injury, the user
must read the instruction manual.
f
Wear ear protectors with Impact drills. Exposure
to noise can cause hearing loss
Electrical safety
#
This tool is double insulated; therefore no earth
wire is required. Always check that the power
supply corresponds to the voltage on the rating
plate.
uIf the supply cord is damaged, it must be replaced by the
manufacturer or an authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
1. Variable speed switch
2. Lock on button
3. Forward/reverse switch
4. Drilling mode selector
5. Twin sleeve Chuck
6. Side handle
7. Depth gauge hole
Assembly
Warning! Before assembly, make sure that the tool is
switched off and unplugged.
Fittingthesidehandleanddepthstop(g.A)
uTurn the grip counterclockwise until you can slide the side
handle (6) onto the front of the tool.
uRotate the side handle into the desired position ensuring
that the notches (6a) engage with the notches on the tool
(5a).
uTo release and turn, slide the handle forward to adjust and
then make sure it is re-engaged with the notches for use.
uInsert the depth gauge (not supplied) into the mounting
hole (7) as shown.
uSet the drilling depth as described below.
uTighten the side handle by turning the grip clockwise.
Settingthedrillingdepth(g.A)
uSlacken the side handle (6) by turning the grip counter-
clockwise.
uSet the depth gauge (not supplied) to the desired position.
The maximum drilling depth is equal to the distance be-
tween the tip of the drill bit and the front end of the depth
gauge.
uTighten the side handle by turning the grip clockwise.
Fittinganaccessory(g.B)
uOpen the chuck by turning the sleeve (5) counterclock-
wise.
uInsert the bit shaft (8) into the chuck.
uTighten the chuck by turning the sleeve clockwise.
Use
Warning! Let the tool work at its own pace. Do not overload.
Warning! Before drilling into walls, oors or ceilings, check for
the location of wiring and pipes.
Switchingonandoff(g.C)
uTo switch the tool on, press the variable speed switch (1).
The tool speed depends on how far you press the switch.
uFor continuous operation, press the lock-on button (2) and
release the variable speed switch. This option does not
work in reverse rotation.
uTo switch the tool off, release the variable speed switch.
To switch the tool off when in continuous operation, press
the variable speed switch once more and release it.
Selectingthedirectionofrotation(g.D)
For drilling and tightening screws, use forward (clockwise)
rotation. For loosening screws or removing a jammed drill bit,
use reverse (counterclockwise) rotation.
uTo select forward rotation, push the forward/reverse slider
(3) to the left.
uTo select reverse rotation, push the forward/reverse slider
to the right.
Warning! Never change the direction of rotation while the
motor is running.
Selectingthedrillingmode(g.E)
uFor Impact drilling in masonry and concrete, set the
drilling mode selector (4) to the
q
position.
uFor drilling in steel, wood and plastics or for screw driving
set the operating mode selector (4) to the
r
position.
Accessories
The performance of your tool depends on the accessory used.
BLACK+DECKER accessories are engineered to high quality
standards and designed to enhance the performance of your
tool. By using these accessories you will get the very best
from your tool.
Maintenance
Your BLACK+DECKER corded/cordless appliance/tool has
been designed to operate over a long period of time with a
minimum of maintenance. Continuous satisfactory operation
depends upon proper tool care and regular cleaning.
Warning! Before performing any maintenance on corded/
cordless power tools:
uSwitch off and unplug the appliance/tool.
