Beware of sharp blades.
Beware of ying objects. Keep
bystanders away from the
cutting area.
Keep the cable away from the
cutting blades.
The blades will continue to
rotate after the machine is
switched off.
Electrical safety
Warning! This tool is double
insulated; therefore no earth
wire is required. Always
check that the power supply
corresponds to the voltage on
the rating plate.
u If the supply cord is damaged, it must
be replaced by the manufacturer or an
authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
u Electric safety can be further improved
by using a high sensitivity 30 mA
Residual Current Device (RCD).
Features
This appliance includes some or all of the following features.
1. Power button
2. Comfort grip handles
3. On/off switches
4. Upper handle
5. Handle knobs
6. Lower handle
7. Grass box handle
8. Carrying handle
9. Grass collection box
10. Rear ap
Assembly
Warning! Before assembly, make sure that the appliance is
switched off and unplugged.
Assembling the grass collection box (g. A, B
and C)
The grass box requires assembly before use and comes in 3
pieces.
u Clip the handle (7) into the lid (9a) of the grass box
(g. B). The handle will only t one way round.
u Align the lid (9a) onto the base of grass collection box
(9b). Ensure that the guides are aligned (g. C)
Note: Take extra care when aligning the 2 clips at the rear of
the grass collection box.
u Push down on the lid to secure all clips. Begin at the back
and ensure that all clips are securely located.
Fitting the lower handle (g. D)
u Insert the ends of the lower handles (6) into the
corresponding holes in the mower.
u Press the handle down as far as it will go.
u Secure the handle using the screws.
Assembling the upper handle (g. E)
u Fit the upper handle (4) to the lower handle (6) using the
knobs (5), washers and screws as shown.
Note: The upper handle can be xed in 2 different height
positions.
Fitting the grass collection box (g. F)
u Lift the ap (10) and place the grass collection box (9)
over the lugs.
Proper Hand Position (Fig. G)
Warning! To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.
Warning!: To reduce the risk of serious personal injury,
ALWAYS hold securely in anticipation of a sudden
reaction.
Proper hand position requires one hand on each of the
comfort grip handles ( 2 ).
Adjusting the height of cut (g. H)
Warning! Ensure the blade has completely stopped and
disconnect the appliance from the mains.
The height of cut is adjusted by altering the height of all the
wheels, there are 3 positions to choose from.
u Remove the grass collection box (9).
u Turn the lawnmower upside down.
u Take hold of a wheel and push/pull the axle from its
current location.
u Move the wheel up/down into the next available location.
