Black+Decker KW1200E - Router Bits and Technical Data; Router Bits (Optional); Technical Data; Maintenance

11
ENGLISH
(Original instructions)
u You can use the tool without a guide (g. N). This is useful
for signwriting and creative work. Only make shallow cuts.
u Refer to the table below for common types of router bits.
Routerbits(Optional)(g.O)
Description Application
Straight bit (1) Grooves and rebates.
Trimming bit (2) Trimming laminates or hardwood;
accurate proling using a template.
Rebating bit (3) Rebates on straight or curved
workpieces.
V-grooving bit (4) Grooves, engraving and edge
bevelling.
Core box bit (5) Fluting, engraving and decorative
edge
moulding.
Cove bit (6) Decorative edge moulding
Ogee moulding bit (7) Decorative edge moulding
Rounding over bit (8) Rounding over edges
Dovetail bit (9) Dovetail joints
Chamfer bit (10) Chamfer edges
Maintenance
Your tool has been designed to operate over a long period of
time with a minimum of maintenance. Continuous satisfactory
operation depends upon proper tool care and regular cleaning.
Warning! Before performing any maintenance, switch off and
unplug the tool.
u Regularly clean the ventilation slots in your tool using a
soft brush or dry cloth.
u Regularly clean the motor housing using a damp cloth.
Do not use any abrasive or solvent-based cleaner.
Mainsplugreplacement(U.K.&Irelandonly)
If a new mains plug needs to be tted:
u Safely dispose of the old plug.
u Connect the brown lead to the live terminal in the new
plug.
u Connect the blue lead to the neutral terminal.
u Connect the green/yellow lead to the earth terminal.
Warning! Follow the tting instructions supplied with good
quality plugs. Recommended fuse: 13 A.
Protecting the environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with
normal household waste.
Products and batteries contain materials that can be recov-
ered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries according to
local provisions. Further information is available at
www.2helpU.com
Technical Data
KW1200E-
KW1200EKA
Input voltage V
ac
220 - 240
Frequency Hz 50
Power input W 1200
No-load speed min-1 8000 - 28000
Collet size mm 5/16" (8 mm) /1/4"
(6.35 mm) / 6 mm
Max. diameter of router bit mm 30
Max. depth of cut mm 55
Weight kg 3.37
Level of sound pressure according to EN 60745:
Sound pressure (L
pA
) 91.5 dB(A), uncertainty (K) 3 dB(A)
Sound power (L
WA
) 102.5 dB(A), uncertainty (K) 3 dB(A)
Vibration total values (triax vector sum) according
to EN 60745:
Vibration emission value (a
h
) 4.0 m/s
2
,
uncertainty (K) 1.5 m/s
2
EC declaration of conformity
MACHINERY DIRECTIVE
KW1200E, KW1200EKA Router
Black & Decker declares that these products described under
"technical data" are in compliance with:
2006/42/EC, EN 60745-1:2009 + A11:2010,
EN 60745-2-17:2010
These products also comply with Directive 2014/30/EU and
2011/65/EU.
For more information, please contact Black & Decker at the
following address or refer to the back of the manual.
