Blackridge BRC155 - Components and Controls

9
COMPONENTS AND CONTROLS
1. Regulator
2. Pressure switch
3. Belt guard
4. Motor reset button
5. Belt (Not shown)
6. Air filter
7. Oil fill cap
8. Sight glass
9. Tank
10. Wheel
11. Motor cover
12. Twin rubber stoppers
13. Drain tap
14. Handle
15. Tank pressure gauge - Small
16. Tank pressure gauge - Large
17. Air tap - Air outlet
18. Safety valve
19. On/Off button (Red button)
PIC. 1
19
18
6
10
12 1213
6
1
16
15
14
9
8
7
2
2
16 15 17 14
1
3
4
11
